| Brand Name : | QUIC |
| Model Number : | ZX-AFGM-2444S |
| Certification : | CE、FCC、RoHS |
| Price : | USD 280（Negotiable） |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Delivery Time : | 5-8 work days |
Enterprise 32 Ports Gigabit Managed PoE Switch Power 300W Full Gigabit Network Switch
24 Gigabit PoE ethernet ports + 4 Gigabit Ethernet ports + 4 Gigabit SFP optical ports + 1 Console port, of which 1-24 ports support IEEE 802.3af/at international standards, single port maximum power supply power 30W, total machine power 300W, backplane bandwidth 56Gbps, Layer 2 network management function, support routing, DHCP, VLAN, MAC address, ACL access control, QOS, multicast, storm suppression, IPV4/IPV6 and other service functions. Support ring network, extreme speed detection and self-healing function, support 802.1X authentication, ARP intrusion detection, IP source protection, DoS protection and other security control policies, support STP/RSTP/MSTP spanning tree protocol, dynamic/static link aggregation and other network protection functions, support Web/Telnet/CLI/SSH management and maintenance mode, adapt to -10 °C ~ 50 °C wide temperature environment work, AC220V, standard 1U rack, with hanging ears.
| Network Protocols | IEEE 802.3 IEEE 802.3u IEEE 802.3ab/ad/az/af/at IIEEE 802.3x IEEE 802.1q IEEE 802.1p,QoS IGMP Snooping |
| PoE Parameters | PoE Standard: IEEE802.3at (30W) and IEEE802.3af (15.4w) |
| PoE compatibility: IEEE 802.3af/at adaptive | |
| POE port output: DC48-55V | |
| Power Pin Assignment: Power over spare pairs 1/2(+) and 3/6 (-) | |
| Port Lightning Protection | General Mode 6KV, Differential Mode 4KV, ESD 15KV. |
| Network Transmission Medium | 10BASE-T: Cat3, 4, 5 UTP (≤ 100 m) 100BASE-TX: UTP (≤100 m) above Cat5 1000BASE-TX: UTP (≤100 m) above Cat5 |
| Optical | Multimode fiber: 1310nm, 2Km Single mode fiber: 1310nm, 20/40 Km 1550nm, 60/80/100/120Km |
| The LED indicator | SYS, PWR, Link (lines 2, 4) / Act (lines 1, 3) |
| Power Supply | Machine input voltage: AC110-240V; Output: DC52V5.76A Total power: 300W |
| Physical Dimension | Product size (L×W×H): 445mm× 285mm× 45mm Package size (L×WxH): 470mm × 350mm × 120mm Product weight: 3.9kg Package weight:4.6kg |
| Working Environment | Operating Temperature:-20° ~ 55 ° C; Storage Temperature: -40 ° ~ 85 ° C; Operating Humidity: 10% ~ 95%, non-condensing Working height: up to 10,000 feet (3,000 meters) Storage height: up to 10,000 feet (3,000 meters) |
| Certification | CE, FCC,ROHS,CCC |
| MTBF: | 100,000 hours |
|
|
